Clipsal 4CB363/6 Circuit Breaker MCB 3 Pole 63 Amp 415Volt 6kA C Curve, Din Rail Mount, REPLACED by CLIMX9MC363
Code: CLI4CB363/6
Unit of measure:
EACH
Description
Circuit Breaker MCB 3 Pole 63 Amp 415Volt 6kA C Curve, Din Rail Mount, REPLACED by CLIMX9MC363
Features:
• Standard characteristic is C-Curve suits most applications
• Base module = 18mm wide compact standardised and consistent module dimension
• Lift-up terminals Safer ‘no hot spot’ terminations and all cable strands are locked in
• CLI4CB363/6 is replaced by CLIMX9MC363
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
| Poles | 3 Pole |
| Category | Circuit Breakers |
| Standard | AS/NZS 60898, EN 60898 |
| Depth | 78.5mm |
| Colour | White |
| Replaced By | CLIMX9MC363 |
| Supplier Code | 4CB363/6 |
| Voltage | 415VAC |
| Carton Quantity | 40 |
| Height | 81mm |
| Width | 54mm |
| Breaking Capacity | 6kA |
| Curve | C Curve |
| Material | Metal and Plastic |
| Pole Configuration | 3 Pole |
| Range | Max9 Series |
| Weight | 310g |
| Brand Name | Clipsal |
| Mounting | Din Mount |
| Item Name | Circuit Breaker |
| Box Quantity | 5 |
| Length | 73mm |
| Frequency | 50/60Hz |
| Rated Current | 63 Amp |
| Current | 63A |
