Clipsal 56CV550-GY 56 Series Switchplug Combination, Switched Socket Outlet, One Piece Vertical, IP66, 415V, 3 Phase, 50A, 5 Round Pins, Surface Mount, 204mm H x 101mm W x 108mm D, Grey
Code: CLI56CV550GY
Unit of measure:
EACH
Description
Clipsal 56CV550-GY 56 Series Switchplug Combination, Switched Socket Outlet, One Piece Vertical, IP66, 415V, 3 Phase, 50A, 5 Round Pins, Surface Mount, 204mm H x 101mm W x 108mm D, Grey
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
| Poles | 3 Pole |
| Phase | 3 Phase |
| Mount | Surface |
| Standard | AS/NZS3123, AS 60529, AS/NZS3133, AS/NZS3112, AS4417 |
| Depth | 108mm |
| Colour | Grey |
| Gang | 1 Gang |
| Supplier Code | 56CV550-GY |
| Connection Type | Screw Terminal |
| Voltage | 500V |
| Number of Pins | 5 Pin |
| Height | 204mm |
| Width | 101mm |
| Material | Polycarbonate and Phosphor Bronze |
| Range | 56 Series |
| Weight | 1.27kg |
| Brand Name | Clipsal |
| Item Name | Switchplug Combination |
| Number of Modules | 2 Modules |
| Box Quantity | 1 |
| Sockets | 1 Socket |
| IP Rating | IP66 |
| Frequency | 50Hz |
| Current | 50A |
