Clipsal 56E4-CG Mounting Back Box, Clipsal - 56 Series, 4 Gang, Vertical Socket Mounting, Dark Grey
Code: CLI56E4CG
Unit of measure:
EACH
Description
Clipsal 56E4CG 56 Series Enclosure, Mounting Base Only, IP66, 4 Gang, 198mm H x 198mm W x 63mm D, Surface Mount, 2 X 25mm & 2 X 32mm Conduit Entries, Chemical Grey
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
| Shape | Square |
| Colour code | CG |
| Mount | Surface |
| Standard | AS/NZS3123, AS 60529, AS 3100 |
| Ambient air temperature for operation | -25-75 °C |
| Depth | 63mm |
| Colour | Dark Grey |
| Mounting mode | wall-mounted |
| Gang | 4 Gang |
| Supplier Code | 56E4-CG |
| Height | 198mm |
| Carton Quantity | 10 |
| Width | 198mm |
| Compatibility code | 56 Series covers |
| Cable entry number | 4 |
| Number of mounting holes | 16 |
| Material | PVC (polyvinyl chloride): housing |
| IP degree of protection | IP66 conforming to AS 60529 |
| Range | 56 Series |
| Standards | AS 3100 |
| Weight | 0.745kg |
| Brand Name | Clipsal |
| Device mounting | surface |
| Item Name | Enclosure |
| Number of Modules | 4 Modules |
| Box Quantity | 1 |
| Length | 63mm |
| IP Rating | IP66 |
| Net weight | 0.745 kg |
