Clipsal 56P332-GY Straight Plug, Clipsal - 56 Series, IP66, 250V 32A - 3 Round Pins, Grey
Code: CLI56P332GY
Unit of measure:
EACH
Description
Clipsal 56P332-GY 56 Series Plug - 3 Pin - 32a - 250v
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
| Poles | 1 Pole + N + E |
| Mount | Lead |
| Ambient air temperature for operation | -25-75 °C |
| Supplier Code | 56P332-GY |
| Connection Type | Screw Terminal |
| Number of Pins | 3 Pin |
| Targeted country | Australia |
| Duration | 6 h |
| IP degree of protection | IP66 conforming to AS 60529 |
| Range | 56 Series |
| Weight | 0.38kg |
| Item Name | Plug Top |
| Box Quantity | 1 |
| Cable entry | cable gland |
| Market segment | utility |
| Current | 32A |
| Connections - terminals | screw terminal 2.5-25mm² |
| Phase | 1 Phase |
| Shape | Cylindrical |
| Colour code | GY |
| Standard | AS/NZS3123, AS 60529, AS/NZS3120, AS/NZS3133, EN 60309 |
| [In] rated current | 32 A |
| Depth | 168mm |
| Colour | Grey |
| Voltage | 250V |
| Height | 79mm |
| Carton Quantity | 24 |
| Poles description | 1P + N + E |
| Width | 79mm |
| Plug- socket category | low voltage |
| Outlet standard | industrial |
| Plug- socket- control station shape | straight |
| Wire stripping length | 20mm |
| Contacts material | pins: brass |
| Device application | power supply |
| [Ue] rated operational voltage | 250 V AC 50 Hz conforming to EN 60309-2 |
| Material | polycarbonate: housing |
| Standards | AS/NZS 3123 |
| Brand Name | Clipsal |
| Voltage colour | blue |
| Angle | Straight |
| IP Rating | IP66 |
| Frequency | 50Hz |
| Net weight | 0.38 kg |
| Thread type | M40 |
| Pin arrangement | B |
| Product or component type | plug |
