Clipsal MX9R3240 Max9 Series RCBO, Type A, C Curve, 1 Pole, 1P+N, 240V, 40A, 30mA, 6KA, Din Rail Mount, 2 Module
Code: CLIMX9R3240
Unit of measure:
EACH
Description
Clipsal MX9R3240 MAX9 Residual Current Breaker with Overcurrent Protection (RCBO), 1PN, 40A, 30mA, C Curve, 6kA, A Type, 2 Module, Din Rail Mount, IP20
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
| Warranty | 7 Years |
| Standard | IEC 61009-1, IEC 61009-2-2, BS EN 61009-1, AS/NZS 61009.1 |
| Pole Configuration | 1 Pole |
| Material | Metal and Plastic |
| Range | Max9 Series |
| Depth | 75mm |
| Weight | 268g |
| Colour | White |
| Brand Name | Clipsal |
| Item Name | RCBO |
| Box Quantity | 1 |
| IP Rating | IP20 |
| Supplier Code | MX9R3240 |
| Voltage | 240V AC |
| Frequency | 50/60Hz |
| Height | 91mm |
| Carton Quantity | 6 |
| Current | 40A |
| Width | 36mm |
| Breaking Capacity | 6kA |
