Clipsal WMC315D Switch Socket Outlet Combination, Metal Clad, 2 Gang, 250V, 2 Pole, 3 Flat Pins, Yellow
Code: CLIWMC315D
Unit of measure:
EACH
Description
Clipsal WMC315D Switched Socket Outlet 1 Gang Dp 15a 250v, 3 Flat Pins, Cast Aluminium Material.
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
| Poles | 1 Pole + N + E |
| Phase | 1 Phase |
| Shape | Rectangular |
| Mount | Surface |
| Standard | AS/NZS 3112, AS/NZS 3100 |
| Depth | 116mm |
| Colour | Yellow |
| Gang | 1 Gang |
| Supplier Code | WMC315D |
| Connection Type | Screw Terminal |
| Voltage | 240V |
| Number of Pins | 3 Pin |
| Height | 239mm |
| Width | 99mm |
| Material | Aluminium |
| Range | Clipsal |
| Weight | 1.8kg |
| Brand Name | Clipsal |
| Item Name | Switchplug Combination |
| Number of Modules | 2 Modules |
| Box Quantity | 1 |
| Sockets | 1 |
| IP Rating | IP66 |
| Frequency | 50Hz |
| Current | 15A |
