Description
IPD 1 NS2, Fuse Link HRC, NS Series, 2Amp 660VAC, 80kA, Class gG, Type NS Offset Blade Tag, 13.5mm x 59mm
Fuse Link HRC, NS Series, 2Amp 660VAC, 80kA, Class gG, Type NS Offset Blade Tag, 13.5mm x 59mm.
Features:
• The element of an HRC fuse is similar to that of a regular fuse. .
• It is manufactured from a metal such as silver that is designed to melt at a predetermined temperature.
• When the fuse is operating within it's normal current range, the heat in the element is dissipated without causing any damage to the element.
• HRC Fuses do not deteriorate with age, providing reliable operation.
• HRC Fuse (High Rupturing Capacity Fuse).
• Use in fuse-holder SC32.
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
| Size | 13.5mm x 59mm |
| Connection | Offset Blade Tag |
| Utilisation Category | Class gG |
| Fuse Type | HRC |
| Standard | BS 88-1 or 6:1988, IEC 269-1, ASTA 20 Certified |
| Range | NS Series |
| Brand Name | IPD |
| Box Qty | 10 |
| Item Name | Cartridge Fuse |
| UOM | EA |
| Type | Type-NS |
| Interrupt Rating | 80 kA |
| Voltage | 415VAC |
| UNSPCS | 39122210 |
| Breaking Capacity AC (kA) | 80kA |
| Rated Current | 2 Amp |
| Current | 2Amp |
| Standards and Approvals | BS88-1 & 6, AS 60269, IEC 269-2-1, ASTA20 Certified |
