Harting 09-30-016-1255 Hood Surface mount Housing With thermo-plastic cover Han B Series Type Low Contruction Size: 16 B Single locking lever Side Entry 1x PG21 Material (hood/housing): Aluminium die-cast
Code: HAR93001611255
Unit of measure:
EACH
Description
HARTING 09-30-016-1255 Hood Surface mount Housing With thermo-plastic cover Han B Series Type Low Contruction Size: 16 B Single locking lever Side Entry 1x PG21 Material (hood/housing): Aluminium die-cast
Features:
• Standard hoods/housings for industrial connectors
• Low Construction
• Degree of protection acc. to IEC 60529 : IP65, IP66, IP67
• Han B Base Surface LC 1 Lever Thermoplas
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
| Number of pins | Housing ONLY |
| Range | Han B Series |
| Weight | 292.8 grams |
| Colour | Powder-coated RAL 7037 (dust grey) |
| Brand Name | Harting |
| UOM | Each |
| Box Quantity | 1 |
| IP Rating | Degree of protection acc. to IEC 60529 : IP65 , IP66 , IP67 |
| Length | 117mm |
| UNSPCS | 39121300 |
| UNSPSC | 39121300 |
| Rated Current | Single locking lever |
| Height | 57mm |
| Width | 55.8mm |
