Description
CBI Electric HEISFM3-G3-32-2 SFM Miniature Circuit Breaker, 3 Pole, 32A, 6kA Breaking Capacity, Clip Tray Mount, IP2X, 240V, 77.4mm Length, White
The CBI Electric MCB SFM Curve 2 is a high-performance miniature circuit breaker designed for reliable protection in electrical systems. With a rated current of 32A and a breaking capacity of 6kA, this 3-pole circuit breaker is ideal for various applications requiring robust safety measures. It operates at a voltage of 240V and features a C curve, making it suitable for inductive loads.Constructed with IP2X terminals, this circuit breaker ensures safety against accidental contact with live parts. The precision hydraulic magnetic technology allows it to carry 100% of the rated current without thermal memory effects, ensuring consistent performance across its operational temperature range of -40 to 85°C. Additionally, the handle is designed to be sealable and padlockable for enhanced security, making it an excellent choice for both commercial and industrial environments while complying with AS 3111 standards.
Features:
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
| Poles | 3 Pole |
| Phase | 3 Phase |
| Warranty | 1 Year |
| Curve | C |
| Mount | Surface, Clip on or Front Screw |
| Standard | N15215, AS 3111 |
| Pole Configuration | 3 |
| Range | SFM |
| Weight | 200g (per Pole),260g (Auxiliary) |
| Brand Name | CBI Electric |
| Mounting | Clip Tray,Surface |
| Item Name | Circuit Breaker |
| Box Qty | 1 Pack |
| UOM | Metric |
| Length | 77.4mm |
| Voltage | 240V |
| UNSPCS | 39121603 |
| Frequency | 50 - 60Hz |
| Height | 149mm |
| Rated Current | 32A |
| Current | 32A |
| Width | 71.8mm |
| Breaking Capacity | 6kA |
