NHP 385124VACDC Finder 38 Series Relay Interface Modules Relay 6A 1 Changeover 24V AC DC Coil
Code: NHP385124VACDC
Unit of measure:
EACH
Description
NHP 385124VACDC Finder 38 Series Relay Interface Modules Relay 6A 1 Changeover 24V AC DC Coil
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
| Power Rating | 0.2 - 0.9 W |
| Number of contacts as change-over contact | 1 |
| Drive - switching attitude | Mono stable |
| Standard | CSA |
| Voltage type for actuating | AC/DC |
| Depth | 72.1mm |
| With LED indication | Yes |
| Current Type | AC |
| Rated switching power at AC-15 - 230V | 300VA |
| Voltage | 250 VAC |
| Supplier Code | 385124VACDC |
| Height | 88.4mm |
| Breaking capacity at DC-1 - 110V | 0.2A |
| Width | 6.2mm |
| Control supply voltage Us at AC 50HZ | 24V |
| Control supply voltage Us at AC 60HZ | 24V |
| Nominal current | 6A |
| Rated switching power at AC-1 | 1500VA |
| Coil Current Type | AC/DC |
| Type of electric connection | Screw connection |
| Terminal Type | Screwless |
| Material contact | Silver nickel |
| Max. rated operation voltage Ue AC | 400V |
| Type of switch contact | Single contact |
| Frequency Rating | 50/60 Hz |
| Nominal voltage AC | 250V |
| Brand Name | NHP |
| Suitable for DIN rail mounting | Yes |
| Item Name | Interface Relay Module |
| EAN/UPC | 2000000194394 |
| Contact Configuration | 1 CO |
| IP Rating | IP20 |
| Control supply voltage Us at DC | 24V |
| Coil Voltage | 24 VAC/DC |
| ETIM Class | Switching relay |
| Number of Poles | 1 |
| Material of contact insert | Thermoplastic |
| Current | 6A |
| Drive - polarization | Polarity free |
