NHP 3PS6D3NE01 PROCONECT 3PS63 Socket Outlet, 3P+N+E, 90A (AC23 63A) 440V AC
Code: NHP3PS6D3NE01
Unit of measure:
EACH
Description
NHP 3PS6D3NE01 PROCONECT 3PS63 Socket Outlet, 3P+N+E, 90A (AC23 63A) 440V AC
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
| Standard | AS/NZS 3947-3, IEC 60309-1, IEC 60529, IEC 60947-3 |
| Material | Nylon PA6 |
| Range | ISO Series |
| Mounting Type | Surface |
| Weight | 0.64kg |
| Brand Name | NHP |
| Item Name | Outlet Switch Socket |
| EAN/UPC | 2000000570419 |
| Nominal tightening torque | 4Nm |
| IP Rating | IP66 |
| Length | 114.5mm |
| Voltage | 380 - 440 VAC |
| Supplier Code | 3PS6D3NE01 |
| UNSPCS | 39121400 |
| Degree of Protection | IP66 |
| ETIM Class | Round socket/plug for high currents |
| Number of Poles | 3 + N + E |
| Current | 90A |
| Operating temperature | -30-60°C |
