NHP CA71601415VAC S+S CA7 Contactor 7.5kW 3Pole 415VAC Coil 1NC Contact Auxiliary
Code: NHPCA71601415VAC
Unit of measure:
EACH
Description
NHP CA71601415VAC S+S CA7 Contactor 7.5kW 3Pole 415VAC Coil 1NC Contact Auxiliary
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
| Poles | 3 Pole |
| Standard | cULus, CE, UL, CSA |
| Voltage type for actuating | AC |
| Number of normally closed contacts as main contact | 0 |
| Depth | 86.5mm |
| Power consumption - AC coil hold-in | 9.5VA |
| Power consumption - AC coil pickup | 75VA |
| Rated operation current Ie at AC-4 - 400V | 9A |
| Number of auxiliary contacts as normally open contact | 0 |
| Voltage | 400 - 415 - 500 - 690V |
| Supplier Code | CA71601415VAC |
| UNSPCS | 39121529 |
| Height | 81mm |
| Rated operation current Ie at AC-3 - 400V | 16A |
| Rated operation current Ie at AC-1 - 400V | 32A |
| Width | 45mm |
| Number of auxiliary contacts as normally closed contact | 1 |
| Type of electrical connection of main circuit | Screw connection |
| Rated operation power at AC-3 - 690 V | 7.5kW |
| Rated operation power at AC-4 - 400V | 4kW |
| Max. rated operation voltage Ue AC | 690V |
| Weight | 0.39kg |
| Number of normally open contacts as main contact | 3 |
| Rated control supply voltage Us at AC 50HZ | 400-415V |
| Brand Name | NHP |
| Item Name | Contactor |
| Contact Configuration | 1 NC |
| IP Rating | IP2X |
| Mounting method | DIN-rail/screw |
| Coil Voltage | 415VAC |
| ETIM Class | Power contactor - AC switching |
| Rated operation power at AC-3 - 400V | 7.5kW |
| Current | 16A |
| Rated operation current Ie at AC-3 - 690 V | 9A |
