Description
NHP CZE730 S+S CA7 Timer Pneumatic On Delay 30s
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
| Max. shock acceleration | 50g |
| Electrical lifespan (control contacts) | 200000 c (contacts) |
| Clock function - starting with pulse - variable | No |
| Mechanical lifetime (control contacts) | 30000000 c (contacts) |
| Max. vibration acceleration | 4m/s² |
| Mount | Top |
| Voltage type for actuating | AC/DC |
| Function flashing - starting with pause - fixed time | No |
| Depth | 109mm |
| Function pulse shaping | No |
| Time setting accuracy | 5% |
| Function delay-on energization | No |
| Supplier Code | CZE730 |
| Time Delay | 0.3 - 30 msec |
| Function delay on de-energization | No |
| Height | 80mm |
| Width | 22.5mm |
| Function floating contact on energization | No |
| Clock function - starting with pause - variable | No |
| Number of outputs - delayed - change-over contact | 1 |
| Function flashing - starting with pulse - fixed time | No |
| Max. vibration frequency - operational | 100Hz |
| Time range | 30 s |
| Type of electric connection | Screw connection |
| Function floating contact on de-energization | No |
| Rated control supply voltage Us at AC 50HZ | 24-240V |
| Power supply reset time | 50 ms |
| Brand Name | NHP |
| Item Name | Timer |
| EAN/UPC | 9321807001351 |
| Type | Pneumatic/On Delay |
| Suitable for DIN rail (top hat rail) mounting | Yes |
| Power consumption | 0.5 VA |
| Rated control supply voltage Us at DC | 24-48V |
| ETIM Class | Timer relay |
| Function star-delta | No |
| Operating temperature | -25-45°C |
