NHP D7PPOT6 Potentiometer, 22.5mm, 10000 Ohm, Resistive Element, Modular Design, -25 to Plus 70 degree C, 74.5mm Length, Black
Code: NHPD7PPOT6
Unit of measure:
EACH
Description
POTENTIOMETER DIAL OP 22.5MM 10000 OHM
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
| Warranty | 1 Year |
| Dimensions | 22.5 mm dia |
| Standard | CE, CCC, CSA, UL Listed |
| Material | Thermoplastic |
| Weight | 0.1kg |
| Colour | Black |
| Brand Name | NHP Electrical |
| Resistance | 10000 Ohm |
| Item Name | Potentiometer Dial |
| EAN/UPC | 2000000200316 |
| UOM | Metric |
| Length | 74.5mm |
| Degree of Protection | IP66/IP65 |
| Width | 40mm |
