This product has now been replaced with
NHP DTCB10206C Din-T Series Miniature Circuit Breaker, MCB, 2 Pole, 6A, 415V, C Curve, 10KA, Din Rail Mount, 2 Module
Code: NHPDTCB10206C
Unit of measure:
EACH
Description
NHP DTCB10206C Din-T Series Miniature Circuit Breaker, MCB, 2 Pole, 6A, 415V, C Curve, 10KA, Din Rail Mount, 2 Module
Features:
• High speed and rapid arc quenching technology ensuring the highest level of protection is provided
• DIN rail mounting
• Free tripping mechanism even if toggle is locked ON or OFF
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
| Poles | 2 Pole |
| Curve | C Curve |
| Mount | Din Rail |
| Standard | IEC 60898, IEC 60077-16-3, IEC 60947-2, IEC 60068-2, DIN |
| Pole Configuration | 2 Pole |
| Range | DIN-T |
| Depth | 76mm |
| Weight | 0.24kg |
| Brand Name | NHP |
| Item Name | Circuit Breaker |
| IP Rating | IP40 |
| Length | 68mm |
| Connection Type | Cable |
| Voltage | 415V |
| Frequency | 50/60Hz |
| Height | 86mm |
| Current | 6A |
| Width | 36mm |
| Breaking Capacity | 10kA |
