NHP RM1A23A25 Carlo Gavazzi Solid State Relay 25A 1 Phase 24 to 265V AC Switching 20 to 280V AC 22 and 48V DC
Code: NHPRM1A23A25
Unit of measure:
EACH
Description
NHP RM1A23A25 Carlo Gavazzi Solid State Relay 25A 1 Phase 24 to 265V AC Switching 20 to 280V AC 22 and 48V DC
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
| Phase | 1 |
| Mount | Panel |
| Modular version | No |
| Standard | CE |
| Voltage type for actuating | AC/DC |
| Depth | 28.8mm |
| Rated control supply voltage Us at AC 60HZ | 20-280V |
| Number of phases | 1 |
| Rated current In | 25A |
| Voltage | 20 - 280 VAC/22 - 48 VDC |
| Number of contacts as normally open contact | 1 |
| Supplier Code | RM1A23A25 |
| Height | 58.2mm |
| Width | 44.8mm |
| Temperature Rating | -20 to 70 deg C |
| Weight | 0.06kg |
| Operating voltage | 24-265V |
| Rated control supply voltage Us at AC 50HZ | 280-20V |
| Brand Name | NHP |
| Item Name | Solid State Relay |
| Contact Configuration | 1 NO |
| IP Rating | IP20 |
| Rated control supply voltage Us at DC | 22-48V |
| ETIM Class | Solid state relay |
| Current | 25A |
