Description
Schneider LAD4RCE TeSys, RC CIR-Clip On Contactor D09.38 3P 24
TeSys D suppressor module, for LC1D09-D38, LC1DT20-DT40 contactors and CAD control relays. To be used with 110-250V AC control circuit voltage, it provides a RC protection limiting the transient voltage to 3 Uc max. Clip-on side mounting, overall size of the contactor is unchanged. Green Premium compliant (RoHS/REACh).
Features:
• Meet the need for coil protection for TeSys Deca contactor
• Easier to install.
• Digital customer experience for technical documents
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
| [Uc] control circuit voltage | 110...250 V AC |
| Device short name | LAD4 |
| Compatibility code | LAD4 |
| Product compatibility | 4P LC1D098...D258 |
| Maximum peak voltage | 3 Uc |
| IP degree of protection | IP2X conforming to IEC 60529 |
| Range | TeSys Deca control relay |
| Suppressor technology | RC circuit |
| Weight | 0.012 kg |
| Standards | CSA C22.2 No 60947-5-1 |
| Ambient air temperature for operation | -25-55 °C |
| Product certifications | CSA |
| Brand Name | Schneider Electric |
| Mounting mode | by clips |
| Supplier ref | LAD4RCU |
| Supplier Code | LAD4RCU |
| Ambient air temperature for storage | -40-80 °C |
| Mounting location | side |
| Net weight | 0.012 kg |
| Product or component type | suppressor module |
