Description
Schneider LADN20 TeSys, TeSys Deca, Auxiliary contact block, 2NO, front mounting, screw clamp terminals
TeSys D instantaneous auxiliary contact block, for contactors LC1D, LC1F and control relays CAD. It provides 2NO+2NC contacts (NC mirror certified) rated up to 10A/690V AC, connection by screw clamp terminals. Clip-on front mounting, it procures high reliability and durability. Multi standards certified (IEC, UL, CSA, CCC, EAC), Green Premium compliant (RoHS/REACh).
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
| Poles | 4 Pole |
| Mount | Front |
| Standard | CSA, UL Listed, IEC 60529, IEC 60068, EN/IEC/UL 60947 |
| Material | Metal and Plastic |
| Range | TeSys |
| Depth | 42 mm |
| Weight | 0.05 kg |
| Colour | Dark Grey |
| Brand Name | Schneider Electric |
| Item Name | Auxiliary Contact |
| Box Quantity | 1 |
| Contact Configuration | 2 NO + 2 NC |
| IP Rating | IP20 |
| Supplier Code | LADN22 |
| Voltage | 690 V |
| Connection Type | Screw Terminal |
| UNSPCS | 39121300 |
| Frequency | 50 - 60Hz |
| Carton Quantity | 10 |
| Height | 48 mm |
| Current | 10A |
| Width | 44 mm |
