Schneider Electric MB248D32 MB Encapsulated distribution board, Acti9, 48 poles, 250A main switch, 18mm, IP42, Grey
Code: SCHMB248D32
Unit of measure:
EACH
Description
Clipsal MB/MD Distribution Board SWBD MB 48P C60 IP42 250A. MB248D32 REPLACES 4MC48M250.
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
| Poles | 48 Pole |
| Enclosure material | steel |
| Mount | Surface |
| Enclosure mounting | surface |
| Depth | 235mm |
| Colour | Grey |
| Enclosure type | standard |
| Supplier Code | MB248D32 |
| UNSPCS | 39121324 |
| Breaking capacity | 25 kA |
| Height | 1000mm |
| Poles description | 3P + N |
| Network frequency | 50 Hz |
| Width | 580mm |
| Device short name | MB |
| Device application | distribution |
| Door type | external plain |
| [Ue] rated operational voltage | 415 V |
| [Ui] rated insulation voltage | 500 V |
| IP degree of protection | IP42 |
| Range | Acti9 |
| Brand Name | Schneider Electric |
| Item Name | Panelboard |
| [Uimp] rated impulse withstand voltage | 6 kV |
| Product name | Acti9 encapsulated DB |
| IP Rating | IP42 |
| Provided equipment | 2 earth/neutral terminal block - top and bottom 165 A |
| Current | 250A |
| [Ie] rated operational current | 250 A |
| Product or component type | distribution board |
