Description
Schneider XB5KS2M8 Harmony XB5, Illuminated buzzer, plastic, yellow, Ø22, continuous or intermittent tone, 230…240 V AC
This Harmony XB5, annunciator siren is supplied with 24V AC/DC with noise level 85dB. This annuciator siren provides a signaletic sound alarm for your installation. It is easily installed into standard 22mm diameter cut-outs. It has an IP40 protection. Its plastic bezel makes it ideal for applications requiring good resistance to chemical agents and/or double electrical insulation.
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
| [Us] rated supply voltage | 24 V +/- 10 % |
| Supply circuit type | AC/DC |
| Loudness Level | 85 dB |
| Mount | Panel |
| Cap/operator or lens colour | black |
| Depth | 55mm |
| Ambient air temperature for operation | -40-70 °C |
| Noise level | 90 dB 6.8 kHz 0.1 m +/- 10 % |
| Current consumption | <= 28 mA |
| Supplier Code | XB5KSB |
| Voltage | 24 V AC/DC |
| Ambient air temperature for storage | -40-70 °C |
| Degree of Protection | IP40 |
| Height | 29mm |
| Mounting diameter | 22mm |
| Width | 29mm |
| Diameter | 22 mm |
| Operating Temperature | -25 to 70 deg C |
| NEMA degree of protection | NEMA 13 |
| Dimensions | 30 mm x 30 mm x 60 mm |
| Head type | standard |
| Range | Harmony XB5 |
| Weight | 0.024 kg |
| Standards | JIS C8201-1 |
| Overvoltage category | class II conforming to IEC 60536 |
| Product certifications | BV |
| Brand Name | Schneider Electric |
| Electrical shock protection class | class II conforming to IEC 60536 |
| Item Name | Buzzer |
| EAN/UPC | 3389110102666 |
| Supply frequency | 50/60 Hz |
| Signalling type | continuous or intermittent tone |
| Resistance to high pressure washer | 9000000 Pa at 80 °C- distance : 0.1 m |
| Protective treatment | TH |
| Bezel material | dark grey plastic |
| Net weight | 0.024 kg |
| Current | 5 mA |
| Product or component type | annunciator |
