Unistrut P1068H 90 degree Angle Bracket, 2 Hole, Steel, Hot-Dip Galvanised, 41mm Width, 57mm Height, 0.14kg, Box of 50, Metal Framing, HG Finish
Code: UNIP1068H
Unit of measure:
EACH
Description
90 deg Angle Fitting
Brand Name: Unistrut
Type: 2 Hole
Hole Size: 14 mm
Width: 41 mm
Thickness: 6 mm
Depth: 57 mm
Finish: Hot Dip Galvanized
Mounting Type: 21 mm From End
48 mm on Center Hole Spacing
Weight: 17 kg
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
| Finish/Color | Hot Dip Galvanized |
| Size | 41mm |
| Hole Size | 14 mm |
| Mounting Type | 21 mm From End, 48 mm on Center Hole Spacing |
| Depth | 57 mm |
| Weight | 0.14kg |
| Brand Name | Unistrut |
| Thickness | 6 mm |
| Item Name | 90 deg Angle Fitting |
| EAN/UPC | 2000000105147 |
| Box Qty | 50 |
| Type | 2 Hole |
| UOM | Imperial |
| Supplier Code | P1068H |
| UNSPCS | 39131711 |
| Height | 57mm |
| Width | 41mm |
| Finish | Hot Dip Galvanized |
| Number of Entries | 2 |
